Developing understanding of diffusion and dissolving

Developing understanding is a series of resources that encourage learners to connect their thinking at the macroscopic, sub-microscopic and symbolic levels.

Learning objectives

1. Predict the gradual diffusion of a coloured dye in water.
2. Explain the diffusion of a coloured dye in water in terms of the random movement of the dye and water particles.
3. Connect understanding of diffusion and dissolving to predict and explain observations when a coloured crystal is placed in water.

This resource aims to develop learners’ understanding of diffusion and dissolving. The questions encourage learners to think at the sub-microscopic level about how the observation of colour spreading through water can be explained in terms of the movement of particles. As a result, learners should develop more secure mental models to support their thinking about this topic.

• When to use? Use after initial teaching or discussion of this topic to develop ideas further. You can also use as a revision activity.
• Group size? Suitable for independent work either in class or at home. Or use the questions for group or class discussions.
• How long? 15–30 mins

Johnstone’s triangle

Johnstone’s triangle is a model of the three different conceptual levels in chemistry: macroscopic, symbolic and sub-microscopic. You can use Johnstone’s triangle to build a secure understanding of chemical ideas for your learners.

Introduce learners to Johnstone’s triangle with our Diffusion of colour in water Johnstone’s triangle worksheet which guides learners to observe and describe the macroscopic diffusion of colour in water using symbolic and sub-micrscopic levels of thinking.

Johnstone’s triangle and this resource

The icons in the margin indicate which level of understanding each question is developing to help prompt learners in their thinking.

• Macroscopic: what we can see. Think about the properties that we can observe, measure and record.
• Sub-microscopic: smaller than we can see. Think about the particle or atomic level.
• Symbolic: representations. Think about how we represent chemical ideas including symbols and diagrams.

The levels are interrelated, for example, learners need visual representation of the sub-microscopic in order to develop mental models of the particle or atomic level. Our approach has been to apply icons to questions based on what the learners should be thinking about.

Questions may be marked with two or all three icons, indicating that learners will be thinking at more than one level. However, individual parts of the question may require learners to think about only one or two specific levels at a time.

Support

This worksheet is ramped so that the earlier questions are more accessible. The activity becomes more challenging in the later questions. You can give extra explanations for the more challenging questions. If completing as an in-class activity it is best to pause and check understanding at intervals, as often one question builds on the previous one.

It is useful for learners to observe macroscopic properties first-hand. You could circulate examples of substances in the classroom, run a class practical of a chemical reaction or show a teacher demonstration of properties.

Give learners physical models to use and manipulate, such as a Molymod™ kits or counters.

Additional support may be needed for any learners still lacking in confidence in the required symbolic representation, for example by sharing and explaining a diagram or a simulation that can show movement of the particles.

Answers and guidance

There are two multi-part questions in the student worksheet. The first question develops learners’ understanding of what is observed when a drop of dye added to water diffuses (macroscopic understanding) and how this can be explained in terms of the random movement of particles (sub-microscopic understanding).

The second develops learners’ understanding of observations of a coloured crystal dissolving in water and the gradual diffusion of the dissolved substance through the water (macroscopic understanding). The question also requires learners to connect the gradual spread of colour with the diffusion of particles of the coloured crystal (sub-microscopic understanding).
